Appendix B
Changing Parameters Using a Terminal Device
67
SRL-35 Operator’s Manual P/N: 1003224-01
Now all of the modifications of the example have been performed and the new values are displayed:
Number 4 is pressed in the main menu.
Serial port 1
Settings
--------------
1) Port status ON
2) Data speed 9600 bit/s
3) Data bits 8 bit data
4) Parity bits None parity
5) Stop bits 1 stop bit
Enter selection or ESC to previous menu >2
Serial port 1 data speed
------------------------
1) 300 bit/s
2) 600 bit/s
3) 1200 bit/s
4) 2400 bit/s
5) 4800 bit/s
6) 9600 bit/s
7) 19200 bit/s
8) 38400 bit/s
Enter selection or ESC to previous menu >7
Serial port 1
Settings
--------------
1) Port status ON
2) Data speed 19200 bit/s
3) Data bits 8 bit data
4) Parity bits None parity
5) Stop bits 1 stop bit
