Repeater Mode and Addressing
Addressing
40
SRL-35 Operator’s Manual P/N: 1003224-01
Transmission:
Reception:
Transmission address has been set OFF. Radio
modem will transmit the data packet as such.
Transmission addressing has been set ON. The
radio modem will add the primary TX address
to the beginning of the data packet.
Reception addressing has been set ON and
either the primary or secondary RX address of
the radio modem is identical to the address of
the received data packet.
The radio modem will remove the address and
send the actual data to the RS-232 interface.
However, if the ”RX Address to RX-line” setting
is on, the radio modem does not remove the
address.
Reception addressing has been set ON, but
both the primary and secondary RX addresses
of the radio modem are different from the
address of the received data packet.
Data does not appear on the RS-232 -
interface.
