Settings
Changing Parameters using the LCD Display
29
SRL-35 Operator’s Manual P/N: 1003224-01
Select FEC
Saving Parameter Setup Changes
TrimTalk, and Pacific Crest Mode Settings
In order to use the Pacific Crest/TRIMTALK modes implemented in the SRL-35 modem:
PACIFIC CREST modems must have:
Protocol Mode =
•^: Transparent w/EOT Timeout (when using Pacific Crest modulations)
•^: TrimTalk 450s (when using TRIMTALK GMSK modulation)
Press ▲ or ▼ until the display panel and the
cursor > points to “Select FEC” and press ”Select”
to move onto the next submenu to turn FEC off or
on.
SELECT
> FEC OFF
EXIT ▲▼ Select
Press ▲ or ▼ until the desired FEC setting is
selected and press “SET” if the FEC setting is to be
modified. Press “CANCEL” if not modifying FEC
setting and return to previous menu.
> FEC OFF
FEC ON
CANCEL ▲▼ SET
Satel FEC ON/OFF has an effect to Satel-3AS protocol only. It is necessary to make sure that
FEC is off for the radio to transmit correctly if using protocol other than Satel-3AS.
To return to the Data Transfer Mode screen press
“EXIT”.
Select Channel
> Ch4 10W
462.37500/12.5
EXIT ▲▼ Select
If radio parameters are modified, press “YES” to
write all changes to radio. Press “NO” to disregard
changes and return to Data Transfer Mode screen.
Save changes?
NO YES
