Topcon SRL-35 - Modification of Handshaking Functions

Appendix B
Changing Parameters Using a Terminal Device
70
SRL-35 Operator’s Manual P/N: 1003224-01
Modification of Handshaking Functions
Handshaking related configuration settings can be modified by selecting the options from the main menu
”6”. In the following example characteristics of the CTS-line (CLEAR TO SEND  TX BUFFER STATE), CD-line
(RSSI-THRESHOLD  DATA ON CHANNEL) and RTS-line (IGNORED
 FLOW CONTROL) are changed.
Number 6 is pressed in the Main menu.
Serial ports 1 and 2 Handshaking
--------------------------------
1) CTS line property Clear to send
2) CD line property RSSI-threshold
3) RTS line property Ignored
4) Pause length 3 bytes
Enter selection or ESC to previous menu >1
Select CTS line action property
-------------------------------
1) Clear to send
2) TX buffer state
Enter selection or ESC to previous menu >2
Serial ports 1 and 2 Handshaking
--------------------------------
1) CTS line property TX buffer state
2) CD line property RSSI-threshold
3) RTS line property Ignored
4) Pause length 3 bytes
Enter selection or ESC to previous menu >2
Select CD line action property
------------------------------
1) RSSI-threshold
2) Data on channel
3) Always ON
Enter selection or ESC to previous menu >2
Serial ports 1 and 2 Handshaking
--------------------------------
1) CTS line property TX buffer state
2) CD line property Data on channel
3) RTS line property Ignored
4) Pause length 3 bytes
