Appendix B
Changing Parameters Using a Terminal Device
69
SRL-35 Operator’s Manual P/N: 1003224-01
Now all of the modifications of the example have been performed and the new values are displayed
:
The settings of the serial port must be modified to correspond with the settings of the terminal device that
is to be connected to the radio modem.
Serial port 1
Settings
--------------
1) Port status ON
2) Data speed 9600 bit/s
3) Data bits 8 bit data
4) Parity bits None parity
5) Stop bits 1 stop bit
***** SRL-35 *****
FW: 06.18.x.xx / HW: SPL0005d+EPT / PV: 05.00 / IM: 05 / S/N: YYMMxxxx
-------------------------------------------------------------------------------
Current settings
----------------
1) Radio frequency TX: 468.50000 MHz / RX: 437.00000 MHz /
Ref freq: 460.00000 MHz / Spacing 12.5kHz
2) Radio settings TX power 35W / Signal threshold -110 dBm / FCS OFF /
TX start delay 0ms / Compatibility Satel 3AS / Call sign OFF
3) Addressing RX address ON 0020/0000 / TX address OFF /
RX address to RS port OFF / TX address autoswitch OFF
4) Serial port 1 ON / 19200 bit/s / 7 bit data / Even parity /
2 stop bit
5) Serial port 2 OFF / 9600 bit/s / 8 bit data / None parity /
1 stop bit (TTL)
6) Handshaking CTS Clear to send / CD RSSI-threshold /
RTS Ignored / Pause length 3 bytes
7) Additional setup Error correction OFF / Error check OFF / Repeater OFF /
SL Commands ON / Priority TX / Full CRC16 check OFF /
User Data whitening OFF
8) Routing OFF
9) Tests OFF
A) Restore factory settings
B) Info
E) EXIT and save settings
Q) QUIT without saving
Enter selection >
Press E for Exiting and saving.
