Topcon SRL-35 - Changing Radio Settings

Appendix B
Changing Parameters Using a Terminal Device
64
SRL-35 Operator’s Manual P/N: 1003224-01
Changing Radio Settings
Radio settings which consist of transmitter output power and receiver sensitivity can be configured by
selecting main menu selection ”2”. In the following example both the transmitter output power (35W 
20W) and the receiver sensitivity (-110 dBm  –90 dBm) are changed.
Number 2 is pressed in the Main menu.
The maximum useable sensitivity of the receiver is determined by the channel spacing (=radio interface
data transfer speed) and also by error correction (utilised or not).
Enter selection >2
Radio setup
-----------
1) TX power 35 W
2) Signal threshold -115 dBm
3) TX start delay 0ms
4) Free Channel Scan RX Slave / OFF
5) Radio compatibility Satel 3AS
6) Call sign OFF
Enter selection or ESC to previous menu >1
TX power setup
--------------
1) 10W
2) 20W
3) 25W
4) 35W
Enter selection or ESC to previous menu >2
Radio setup
-----------
1) TX power 20W
2) Signal threshold -115 dBm
3) TX start delay 0ms
4) Free Channel Scan RX Slave / OFF
5) Radio compatibility Satel 3AS
6) Call sign OFF
Enter selection or ESC to previous menu >2
Signal threshold setup
--------------------------
Signal threshold -115 dBm
Enter new value (80 - 118) or ESC to previous menu > -110 Enter
Signal threshold setup
--------------------------
Signal threshold -110 dBm
Enter new value (80 - 118) or ESC to previous menu > -
To get back to the main menu press ESC (and then E for Exiting and saving).
