Radio Interface
RF Interface
9
SRL-35 Operator’s Manual P/N: 1003224-01
Display in Setup Mode
RF Interface
The SRL-35 has a single TNC type RF-connector with impedance of 50 Ohm.
When the modem is supplied the frequency is set to “default channel”. The user can change the frequency
afterwards by 70 MHz. Of course, all local regulations set forth by the authorities must be taken into
consideration.
The data speed of the radio interface is set to “default speed”. It can also be set afterwards.
S/N XXXXXX
FW XXXXXX
Exit
Serial Number
FW: Firmware Version
Board: SPL0005E
+SLR-35
IM:05
Exit
Board: HW version
IM: Interface module type
