Display in Data Transfer Mode (transmit/receive mode)
Info - Setup
By pressing the INFO buon (●) the modem goes to detailed informaon about the modem’s sengs.
By pressing the SETUP button ( ■ ) the modem goes to the programming menu.
Display in Info Mode
Pressing  shows the next window.
n-123 11.5V
CH4 10W
462.37500/12.5
INFO SETUP
n-123: Field strength of last received transmission
or noise level.
11.5V = Supply Voltage/Battery level indicator.
CH4 = Current Channel
10W = Current Output Transmission Power
462.37500 = Operational TX/RX Frequency
12.5 = Channel Spacing
Protocol
PacCrest - 4FSK
Exit 
Protocol
Repeater OFF
FEC OFF
Port 1 9600/8N1
Exit 
Repeater
FEC
Port 1 : Port interface and status
RX Address
RX1 OFF
RX2 OFF
Exit 
RX Address
TX Address
TX1 OFF
TX2 OFF
Exit 
TX Address
