Specifications
46
SRL-35 Operator’s Manual P/N: 1003224-01
Note 1
Due to radio electronic design, the receiver is about 6 – 15 dB less sensitive on the following frequencies:
403.000, 416.000, 429.000, 442.000, 455.000, 468.000, 409.5875 and 469.200 MHz.
Power Consumption < 1.8 W 120 W typical @ 35 W, min 12 Vdc
100 W typical @ 25W
Power Save Mode
Consumption
SLEEP State:0,4 W typical
Communication Mode Half-Duplex
Type of Emission F1D
Carrier power
10, 20, 25, 35 W / 50 ohm (default)
5, 10, 20, 25W / 50 ohm (Option
b
)
Adjacent Channel Power According to EN 55022 and FCC CFR47 part 90
Carrier power stability + 2 dB / - 3 dB
a. If high output power is used continuously or with a high cycle, the equipment generates excess heat. The output power is
automatically decreased when necessary to prevent overheating. Typical operating times are shown in the chart with different output
powers and duty cycles @ 22°C and 35 °C (see chapter 3.2).
b. Limited output power is available as on order option.
Table 21. Data Modem Specifications
DATA MODEM
Timing RS-232
Electrical Interface RS-232
Interface Connector 8-pin ODU
Data speed of
I/O-interface
300 – 38400 bps
Data speed of Radio
Interface
19200 bps (25 kHz channel) /
9600 bps (12.5 / 20 kHz channel)
Data Formats Asynchronous RS-232
Table 22. Radio Protocols
a
a. Use of PDL and Satel protocols is recommended in applications where possible. Compatibility with TrimTalk is subject to
some restrictions.
Protocol Modulation
Link rate
(@ 12.5 kHz)
Link rate
(@ 25 kHz)
Satelline-3AS 4-FSK 9600 19200
PCC 4-FSK 4-FSK 9600 19200
PCC GMSK GMSK 4800 9600
TrimTalk450s(P) GMSK 4800 9600
TrimTalk450s(T) GMSK 4800 9600
PCC-FST GMSK 9600 19200
Table 20. Technical Specifications
