7. Onceyouaresasedthattheaxisofthedowelis
paralleltothespindleaxisinbothXandY,jogthe
spindledowntothetopoftheTormachtoolholder
shank.Donotgoallthewaydowntotheshoulderyet.
Verifybyeyethatitisroughlycenteredonthecollet
centeropening.
• Toadjustthealignmentofthetoolholdertothecollet
intheXdirecon,loosenthejamnutattheendofthe
traycylinderrodandmoveittoaroughlycentered
posion.Press“TrayIn”toverifytheadjustment.You
willlikelyhavetorepeatthisprocedureseveralmes
togetthelocaoncorrect.
• Toadjustthealignmentofthetoolholdertothecollet
intheYdirecon,usethe“--“or“++”-buonsonthe
ATCSetupscreenAlignmentsecon.Itisbesttowiggle
theforkwithyourthumbandindexngertofeelthe
extremesofthecarouselbacklashagainstthespindle
withyourngerstoseethatitisroughlycenteredle
andrightofforkwhilemakingthisadjustment.
