Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e 11
4.1 Lintel Mounting Standard Linkage
T1132/10
T1132/28
L
A
B
45
C
E
F
D
310
540
50
I
90°
M
H
G
80
K
M
T1132/25
8
23
80
310
290
540
20
50
2x Ø7
4x Ø7
30
580
290
20
Z
Y
45
20
X
70.5
116
85
Y
Z
0 – 10 33
X
–40…+107
+105…+252
0 – 70 93
–40…+107
+105…+252
A) Glue on template
B) Drill holes
C) Attach cone, length according Y, surfaces parallel to side
plates
D) Tighten hexagon-socket screw
E) Fasten operator
F) Fasten bearing trestle according to dimensional specifi-
cations on door leaf
G) Attach connecting part at right-angle to the operator to
cone (length in accordance with Y)
H) Interconnect bearing trestle and adjustment member
I) Adjust adjustment member at right-angle to the lintel and
tighten screws
K) Interconnect connecting part and adjustment member
L) Fasten covers
M) Snap in side plates
