Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e 3
First edition: 9.02 provisional for 0-Series
Update: 3.03
We print on environment-friendly paper bleached without chlorine.
The enterprises Landert Motoren AG and Landert GmbH are certified according to ISO 9001.
Contents
1 Introduction 4
2 Safety 5
2.1 General Safety and Accident Prevention
Regulations 5
2.2 Safeguarding Danger Points 6
2.3 Organizational Measures 7
3 Basic Functions 8
4 Installation 10
4.1 Lintel Mounting Standard Linkage 11
4.2 Door Leaf Mounting Standard Linkage 12
4.3 Sliding Lever u 13
4.4 Panic Fitting u 14
5Mechanical Adjustments 15
6 Electrical Connections 16
7 Commissioning of the Automatic System 19
7.1 Commissioning with “Teach-In General” 19
7.2 Programming Procedure 19
7.3 Programming Examples 20
7.4.1 Programmable Functions 22
7.4.2 Effect of Homing in Speed and Angle for Homing in Speed Closing 23
7.5 Low Energy Applications 24
8Trouble Shooting 25
9 Check List 26
Fold-out page
