Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e 23
7.4.2 Effect of Homing in Speed and Angle for Homing in Speed
Closing
a) Closing Speed higher than Homing in Speed
b) Closing Speed lower than Homing in Speed
[°]
v [°/s]
T1132/42e
Speed defined
through Teach-In
closing speed
and maybe speed
limitation
(function 8)
Angle defined through Teach-In open position
All angular data is related
to the drive shaft, not to door leaf
Speed defined through
function 6
homing in speed
increasing angle
homing in speed closing
increasing
homing in speed
Angle defined by function 5
angle homing in speed closing
[°]
v [°/s]
Speed defined
through Teach-In
closing speed
and maybe speed
limitation
(function 8)
Angle defined through Teach-In open position
All angular data is related
to the drive shaft, not to door leaf
Speed defined through
function 6
homing in speed
T1132/43e
increasing angle
homing in speed closing
increasing
homing in speed
Angle defined by function 5
angle homing in speed closing
