7.4.1 Programmable Functions
Function Param
eter
Description of Function
0
Teach-In General 0Automatic teaching procedure for adjustment of the operational behaviour:
Opening and closing speed, open position, hold-open time, disabling angle for safety
device in opening direction
The behaviour applies to opening through activators, key switches and Push-and-Go.
The fitter must carry out Teach-In General for each system!
1 Only the opening speed of Teach-In General is changed.
2 Only the open position of Teach-In General is changed.
Caution: The disabling angle for the safety facility in opening direction is thereby
possiblyregistered anew. The disabling angle applies to all opening motions.
3 Only the hold-open time of Teach-In General is changed (max. 100 minutes).
4Only the closing speed of Teach-In General is changed.
0
Teach-In key switch 5Optional automatic teaching procedure for establishing another operational behaviour
during opening with the key switch (terminal 7–8):
Opening and closing speed, open position, hold-open time.
Caution: The disabling angle for the safety facility in opening direction is thereby
possiblyregistered anew. The disabling angle applies to all opening motions.
6 Only the opening speed of the Teach-In key switch is changed
7 Only the open position of the Teach-In key switch is changed
Caution: The disabling angle for the safety facility in opening direction is thereby
possiblyregistered anew. The disabling angle applies to all opening motions.
8 Only the hold-open time of the Teach-In key switch is changed (max. 100 minutes)
9 Only the closing speed of the Teach-In key switch is changed
1
Push-and-Go 0 Push-and-Go is switched off (standard).
No motor-driven opening takes place on an attempt to open the door manually. The
door closes in a controlled manner as soon as it is released.
1...9 Push-and-Go is switched on.
The door opens automatically in accordance with "Teach-In General" on an attempt to
open the door manually.
The release angle for Push and Go is adjustable from 3 ° to 24 °, measured at the shaft
of the drive unit.
2
Safety devices 0 Safety device in closing direction (e.g. for the safety sensor riding along on the door)
is activated (standard)
1 The safety device for the swing area (e.g. for safety mat) is activated.
2 The safety device Bodyguard is activated.
3
Opening time delay 1 ... 9 After an opening command, the door lock is unlocked immediately.
The motor is only started on completion of the opening time delay so that the door has
sufficient time to unlock. The opening time delay is adjustable from 0.2 to 3.6 s.
4
Special functions 0...7 In this adjustment menu, 3 different functions can be selected in combination
according to the specifications in the programming table:
1. Sequencing according to time or step control
2. Door lock current-free unlocked or current-free locked
3. Feedback of door state: "door closed" or "door open"
5
Angle homing in
speed closing
1...9 The angle homing in speed closing of the door on closing can be adjusted between 4 °
and 36 °. From this position onward, the adjustable damping becomes effective.
(0 = standard value 12 °)
6
Homing in Speed 1...9 The homing in speed closing is effective from angle homing in speed closing and is
thus dependent on this setting. The homing in speed can be adjusted between a
minimum, e.g. end stop for door lock, and maximum homing in speed for softly driving
to the final position.
(0 = standard value with medium homing in speed)
7
Opening force
limitation
0...9 For the deployment as low energy operator, the maximally possible opening force
must not be used. The opening force, given by the motor current, can be limited with
this setting in accordance with the table in section 7.4.
(0 = standard value without force limitation)
8
Speed limitation 0...9 For the deployment as a low energy operator, the opening and closing speeds must be
limited so that the actual opening and closing times will not be shorter than the
requested values specified in the standards. With this setting, the speed obtained
through Teach-In General"and Teach-In key switch can be limited upward in
accordance with the table in section 7.4
(0 = standard value without speed limitation)
9
Reset 1With the factory reset, all programming changes made are reset to the default values
specified at the factory. The system must be re-commissioned in accordance with
section 7.1, Commissioning With Teach-In General.
