26 Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e
9 Check List
After completion of installation and commissioning of the system, the following points are
to be checked before handing the system over to the system operator:
❑ All screws tightened and secured
❑ Cable expertly routed, no brushing against moving parts
❑ Strain relief mounted for the mains cable
❑ OPEN end-stop correctly adjusted.
The door system must correspond to the valid, state-specific regulations.
❑ Dangerous jamming, wedging and shearing positions safeguarded or eliminated
❑ Safety facilities ◆ checked
❑ Adjusted door speed permissible
❑ Emergency-off switch ◆ checked
❑ Size of the detection field reasonably adjusted
❑ Action radius adequate
❑ The activators ◆ cannot be evaded by under-creeping
❑ Lateral sneaking up to the door not possible without detection
❑ Auxiliary activators (key switch ◆ etc..) are functioning
❑ The desired operating modes can be selected with the operating mode selector ◆
❑ Speeds and homing in speed are tuned
❑ Customer requests in accordance with contract order sheet checked
❑ Operation on power failure/power recovery checked
❑ Colour damages repaired, system cleaned
❑ Electrical cabling carried out professionally
❑ No abnormal noises
❑ Good motion control
❑ System labelled
(Company name label with TORMAX support address)
❑ System accepted in accordance with on site acceptance test
❑ Operating instructions supplied
❑ Duty and operation of the system explained
❑ Conduct in case of trouble explained (including possible interventions)
❑ Informed the system operator of his obligations
• Regular checks in accordance with the operating instructions
• Annual service obligation through TORMAX dealer
(in accordance with national regulations)
❑ Service contract offered
Subject to technical changes
Drive Unit
Safety Regulations
Activators ◆
Functions
General Appearance
Acceptance Test
Handing-Over to the System
Operator
