Tornado OB 20/14 User Manual

4
TECHNICAL DESCRIPTION U/M
Cleaning width in/mm 20/500
Squeegee width in/mm 30/770
Working capacity, up to sqft/h/m
2/
h 24,219/2250
Dimensions pad in/mm 19.7x13.8/ 500 x 350
RPM base motor rpm 2200
Pressure on the base lbs/kg 110/50
Base motor W/A 750/31
Traction motor W/A 400/16.7
Suction motor W/A 400/16.7
Suction vacuum water lift/mbar 48/120
Type of drive automatic
Movement speed (max) mph/kph 2-2.8/3.2-4.5
Maximum gradient % 10
Solution tank gal/l 14/53
Reserve solution tank gal/l 1.3/5
Recovery tank gal/l 15/56
Machine length in/mm 49/1244
Machine height in/mm 43.2/1098
Machine width (without squeegee) in/mm 21.6/548
Weight of the machine (empty and without batteries ) lbs./kg 262/119
Voltage V 24
Compartment of the batteries in/mm 15x16x15/390x405x374
Acoustic pressure level
(in conformity with EN 60704-1) Lpa
dB(A) <70
Class
Protection level IP X3
