Cutting Unit Operation Problems
Condition Possible Cause Correction
Engine continues to run (but
should not) when cutting unit
clutch switch is ON with no opera-
tor on the seat.
Seat switch plunger depressed
with no operator on seat.
Check for seat support spring
that is broken, missing or stuck in
down position.
Check for binding seat pivot
hinge.
Check for waterlogged seat.
Seat switch faulty or out of adjust-
ment.
Test seat switch. Adjust or re-
place if faulty.
Cutting units run (but should not)
Cutting unit interlock switch faulty. Test switch and replace if faulty.
when raised, but shut off with cut-
Make sure wires are connected
ting unit clutch switch.
to “COMMON” and “NORMALLY
OPEN” (N.O.) terminals.
Cutting units shut off when
Cutting unit clutch switch faulty. Test switch. Replace if faulty.
raised, but do not shut off with
cutting unit clutch switch.
Cutting units do not engage. “ACC” fuse open. (NOTE: Hourme-
ter and temp. gauge will also fail to
operate.)
Check fuse and replace if fuse is
open. If fuse burns out often, find
and correct cause.
Cutting unit clutch switch faulty. Test switch. Replace if faulty..
Cutting unit clutch switch wiring
loose, corroded or damaged.
Repair wiring.
Cutting unit interlock switch faulty. Test switch and replace if faulty.
Make sure wires are connected
to “COMMON” and “NORMALLY
OPEN” (N.O.) terminals.
Cutting unit interlock switch wiring
loose, corroded or damaged.
Repair wiring.
Clutch faulty or out of adjustment.
Test clutch. Make sure clutch air
gap is properly adjusted..
Clutch wiring loose, corroded or
damaged.
Repair wiring.
Troubleshooting (Reelmaster 216-D) Page 6 - 18 Reelmaster
®
216/216-D
