CurvedHandleInstallation(ElectricStartModelsOnly)(continued)
g353181
Figure88
4.Installthecableguideontothecurvedhandle.
5.Installtheropeguideontothecurvedhandle,securewithanut.Torquethe
nutto4.52±0.56N•m(40±5in-lbs).
g353180
Figure89
6.InstalltheRWDPERSONALPACE®handle.RWDPERSONALPACE®
HandleAssemblyInstallation(page5–25)
7.Installthecableguideandelectricstartertothecurvedhandle,securewith
theNIlocknutand(7/16)bolt.T orquethenutto4.52±0.56N•m(40±
5in-lbs).
8.Installthecableguideontothecurvedhandle.
9.Installthe2cabletiessecuringtheelectricstarterwireharnesstothecurved
handle.
