g020241
Figure24
1.Leftmotion-controllever
5.Forward
2.Rightmotion-controllever6.Neutral
3.Frontreferencebar
7.Reverse
4.Frontofthemachine
DrivingForward
1.Makesurethatthemotion-controlleversarein
theneutralposition.
2.Disengagetheparkingbrake.
3.T omoveforwardinastraightline,moveboth
leversforwardwithequalpressure.
Note:Themachinemovesfasterthefarther
themotion-controlleversaremovedfromthe
neutralposition.
g016672
Figure25
4.T oturnleftorright,pullthemotion-controllever
backtowardneutralinthedesiredturndirection.
Thetinescanbeinthedownpositionwhen
makinggradualturns.
5.T omakezero-turns,liftyourfootoffthetine
engagementfootswitchcontroltoraisethe
tines.Theheadraisesin1second.
Important:Donotmakeazero-turnwhen
thetinesaredown,otherwiseyoumaytear
theturf.
6.T ostopthemachine,movebothmotion-control
leverstotheneutralposition.
DrivinginReverse
1.Movethemotion-controlleverstotheneutral
position.
2.T omoverearwardinastraightline,slowlymove
bothleversrearwardwithequalpressure.
g016673
Figure26
3.T oturnleftorright,releasepressureonthe
motion-controllevertowardthedesiredturn
direction.
4.T omakezero-turns,liftyourfootoffthe
tine-elevationswitchtoraisethetines.Thehead
raisesin1second.
Important:Donotmakeazero-turnwhen
thetinesareinthedownposition.
5.T ostopthemachine,positionbothmotion-control
leversintheneutraloperateposition.
AdjustingtheFront
Reference/Speed-ControlBar
Adjustthefrontreference/speedcontrolbarfor
desiredmaximumforwardspeed.
1.Stopthemachineandmovethemotion-control
leverstotheNEUTRALposition.
2.Loosenthenutsoneachsideofthecontrol
panel(Figure27).
