Toro 29521 - Pre-Maintenance Procedures; Preparing for the Machine for Maintenance; Accessing the Console Compartment

Pre-Maintenance
Procedures
PreparingfortheMachine
forMaintenance
Performthefollowingbeforeservicing,cleaning,or
makinganyadjustmentstothemachine.
1.Parkthemachineonalevelsurface.
2.Shutofftheengine,engagetheparkingbrake,
waitforallmovingpartstostop.
3.Removethekeyfromthekeyswitch.
AccessingtheConsole
Compartment
RemovingtheConsolePad
1.Loosenthe4anged-headboltsthatsecurethe
padtotheleftandrightconsolepanels(Figure
30).
g025880
Figure30
1.Keyholeslot(console
panel)
3.Pad
2.Fanged-headbolt
2.Lifttheconsolepad(Figure30)approximately
13mm(1/2inch).
3.Pulltheconsolepadstraightbackandremove
thepadfromthemachine(Figure30).
InstallingtheConsolePad
1.Alignthe4anged-headboltsattheforward
faceoftheconsolepadtothe4keyholeslotsin
theframeoftheconsole(Figure30).
2.Movethepadforwarduntilthepadisushto
theconsoleframe(Figure30).
3.Movethepaddownuntiltheanged-headbolts
areseatedinthekeyholeslots(Figure30).
4.Tightentheanged-headboltsto1978to2542
N∙cm(175to225in-lb).
