Toro 29521 - Product Overview; Controls

ProductOverview
g269241
Figure5
1.Platform
4.Enginecontrols
2.Parking-brakeknob5.Fuelcap
3.Motion-controllevers
Controls
Motion-ControlLevers
Themotion-controlleversarelocatedoneachsideof
thetopconsoleandcontroltheforwardandreverse
motionofthemachine.
Movetheleversforwardorbackwardtocontrolthe
drivewheelonthesamesideforwardorreverse
respectively.Thewheelspeedisproportionaltothe
amountyoumovethelever.
Important:Thetinesrotatewhenthe
motion-controlleversaremovedoutofthe
NEUTRALposition.
g267503
Figure6
1.Leftmotion-controllever
5.Forward
2.Rightmotion-controllever6.Neutral
3.Frontreferencebar
7.Reverse
4.Frontofthemachine
ThrottleLever
Thethrottlelever(Figure7)islocatedonthecontrol
console(redlever).
Usethethrottlelevertocontrolenginespeed.Move
thethrottleleverforwardtoincreaseenginespeed;
movingthethrottleleverrearwardtodecreasethe
enginespeed.
Note:Movethethrottleleverforwardintothedetent
forfullthrottle.
ChokeLever
Thechokelever(Figure7)islocatedonthecontrol
console(blacklever).
Usethechokeleverisusedtoaidinstartingacold
engine.Movethechokeleverforwardtosetthe
choketotheONposition;movethechokelevertothe
rearwardtoreducethechoke.
Note:Pullthechokeleverbackintothedetenttoset
thechoketotheOFFposition.
Note:Donotrunawarmenginewiththechokein
theONposition.
11
