Toro 30308 - Setup

Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Step
Description
Qty.
Use
Steering wheel
1
1
Cover
1
Install the steering wheel.
Handle
1
2
Screws 2
Install the hood handle.
3
Seat, Model 30398 and the
Mechanical Seat Suspension Kit,
Model No. 30312 or the Pneumatic
Seat Suspension Kit, Model No.
30313 (obtained separately)
1
Install the seat.
Seat belt
2
Bolts
2
Lock washer
2
4
Flat washer
2
Install the seat belt.
Manual tube
1
5
R-clamp
2
Install the manual tube.
6
No parts required
–
Activate and charge the battery.
7
No parts required
–
Adjust the ROPS.
8
No parts required
–
Check the tire pressure.
9
Rear weight kit(s) as needed
-
Install rear weights if needed.
10
No parts required
–
Check the rear axle lubricant,
hydraulic uid, and engine oil levels
Operator’s Manual
1
Engine Operator’s Manual
1
Parts Catalog
1
Operator Training DVD
1
Pre-delivery Inspection Sheet
1
Engine warranty
1
CE certicate
1
Certicate of Quality
1
Roll pin
1
Bolt (5/16 x 1-3/4 inches)
2
Lock nut (5/16 inch)
2
Cylinder pin
2
Cotter pin (3/16 x 1-1/2 inches)
4
11
Brake return springs
2
Read the manuals and watch the
DVD before operating the machine.
Use the remaining parts for the
installation of attachments.
Note: Deter mine the left and right sides of the
mac hine from the nor mal operating position.
