Figure 18
1. Fuel gauge
Ignition Switch
T he ignition switc h has three positions: Off ,
On/Preheat, and Star t. ( Figure 17 ).
Throttle
T he throttle ( Figure 17 ) is used to operate the
engine at v arious speeds . Mo ving the throttle
forw ard to w ard the F ast position increases the
engine speed. Mo ving it rearw ard to w ard the
Slo w position decreases the engine speed. T he
throttle controls the speed of the blades and, in
conjunction with traction pedal, controls g round
speed of the mac hine . T he detent is the high idle
position.
Hour Meter
T he hour meter ( Figure 17 ) registers accum ulated
hours of engine operation.
Engine Coolant Temperature Warning
Light
T he temperature w ar ning light ( Figure 17 ) glo ws
and the implement stops if the engine coolant
temperature is high. If the mac hine is not stopped
and the coolant temperature rises another 20° F ,
the engine will kill.
Glow Plug Indicator
W hen lit, indicates that the glo w plugs are on
( Figure 17 ).
Charge Indicator
Illuminates when the system c harging circuit
malfunctions ( Figure 17 ).
Oil Pressure Warning Light
T he oil pressure w ar ning light ( Figure 17 ) glo ws
when the oil pressure in engine drops belo w a
safe lev el. If lo w oil pressure ev er occurs , stop
the engine and deter mine the cause . R e pair the
damag e before star ting the engine ag ain.
Lift Lever Lock
Loc k the lift lev er ( Figure 17 ), in the raised
position, when perfor ming maintenance on the
dec k.
Specications
Note: Specifications and design are subject to
c hang e without notice .
Length 82 inches
Width (Rear Wheels)
47 inches
Height without ROPS 50 inches
Height with ROPS 77 inches
Weight, Model 30308 1300 lb
Weight, Model 30309 1520 lb
Attachments/Accessories
A selection of T oro appro v ed attac hments and
accessories are a v ailable for use with the mac hine
to enhance and expand its capabilities . Contact
y our A uthorized Ser vice Dealer or Distributor or
g o to www .T oro .com for a list of all appro v ed
attac hments and accessories .
28
