Step
2
Installing the Hood Handle
Parts needed for this step:
1
Handle
2 Screws
Procedure
1. R emo v e and discard the 2 screws and n uts
securing the hood cable brac k et and to the
underside of the hood ( Figure 4 ).
Figure 4
1. Hood cable bracket
2. Mount the handle and the cable brac k et to the
hood with 2 screws ( Figure 5 ).
Figure 5
1. Handle 2. Hood cable bracket
Step
3
Installing the Seat
Parts needed for this step:
1
Seat, Model 30398 and the Mechanical Seat
Suspension Kit, Model No. 30312 or the
Pneumatic Seat Suspension Kit, Model No.
30313 (obtained separately)
Procedure
T he Groundsmaster 3280-D is shipped without
the seat assembly . T he optional Seat, Model 30398
and the Mec hanical Seat Suspension Kit, Model
No . 30312 or the Pneumatic Seat Suspension Kit,
Model No . 30313 m ust be obtained and installed.
R efer to the seat kit for the installation instr uctions .
Note: An A uxiliar y P o w er Unit Kit, Model No .
30382, m ust be obtained and installed before
installing a Pneumatic Suspension Seat Kit to the
mac hine .
Note: R efer to Installing the Man ual T ube before
the seat is mounted to the seat suspension.
Step
4
Installing the Seat Belt
Parts needed for this step:
2
Seat belt
2
Bolts
2
Lock washer
2
Flat washer
Procedure
Install eac h end of the seat belt in the holes in the
bac k of the seat with 2 bolts (7/16 x 1 inc h), flat
w ashers (7/16 inc h), and loc k w ashers (7/16 inc h)
( Figure 6 ).
Important: Mount the latch side of the belt
to the right side of the seat.
17
