Toro 30308 - Installing the Steering Wheel

T he PT O uni v er sal shaft is attached to the
machine frame. Do not enga ge the PT O
without fir st r emo ving the uni v er sal shaft or
coupling it to a suita ble implement.
Step
1
Installing the Steering
Wheel
Parts needed for this step:
1
Steering wheel
1
Cover
Procedure
1. R emo v e the steering wheel from the seat plate .
2. R emo v e the co v er from the steering wheel
( Figure 3 ).
Figure 3
1. Steering wheel 4. Foam collar
2. Jam nut 5. Cover
3. Dust cover
3. R emo v e the jam n ut from the steering shaft.
Ensure that the foam collar and dust co v er are
on the steering shaft ( Figure 3 ).
4. Slide the steering wheel onto the steering shaft
( Figure 3 ).
5. Secure the steering wheel to the shaft with the
jam n ut and tighten it to 17-23 ft-lb .
6. Mount the co v er to the steering wheel
( Figure 3 ).
