Incor r ect batter y ca ble r outing could
dama ge the machine and ca bles causing
spar ks. Spar ks can cause the batter y
gasses to explode, r esulting in per sonal
injur y .
• Al w ays disconnect the negati v e
(black) batter y ca ble bef or e
disconnecting the positi v e (r ed)
ca ble.
• Al w ays connect the positi v e (r ed)
batter y ca ble bef or e connecting the
negati v e (black) ca ble.
Figure 10
1. Positive (+) 2. Negative (-)
Connecting ca bles to the wr ong post
could dama ge the electrical system and
r esult in per sonal injur y .
Note: Ensure that the batter y cables are
routed a w a y from any shar p edg es or mo ving
par ts .
Step
7
Adjusting the ROPS
No Parts Required
Procedure
1. R emo v e the hair pin cotter pins and remo v e the
tw o pins from the roll bar ( Figure 11 ).
Figure 11
1. Roll bar
3. Hairpin cotter pin
2. Pin
2. Raise the roll bar to the upright position and
install the tw o pins and secure them with the
hair pin cotter pins ( Figure 11 ).
Note: If the roll bar m ust be lo w ered, lo w er
it slo wly so damag e to hood does not occur .
