Toro 30308 - Installing Rear Weights

Step
9
Installing Rear Weights
Parts needed for this step:
-
Rear weight kit(s) as needed
Procedure
T he Groundsmaster 3280-D Series mac hines comply with ANSI B71.4-2004 Standard when equipped
with rear w eight. Use c har ts belo w to deter mine combinations of w eight required. Order par ts from
y our local A uthorized T oro Distributor .
Two Wheel Drive Chart Rear Weight
Required
Left Side
Weight
Required
Weight Part
Number
Weight Description
Qty.
52 inch Side Discharge
Deck (Model 30555)
0 lb. 0 lb.
- - -
*77-6700
75 lb. Wheel Weight
1
92-9670
Bracket Kit
1
52 inch Side Discharge Deck
with 15 cu. ft. Hopper
0 lb. 145 lb.*
24-5780
Rear Weight Kit
1
24-5790
Rear Weight, 35 lb
1
325-8
Bolt (1/2 x 2 inches)
2
3253-7
Lock washer (1/2 inch)
2
3-8847 Spacer 2
3217-9
Nut (1/2 inch)
2
24-5780
Rear Weight Kit
1
60 inch Side Discharge
Deck (Model 30366)
or
62 inch Rear Discharge
Deck (Model 30367)
or
62 inch Guardian Recycler
Deck (Model 30376)
170 lb. 0 lb.
108-9682
Rear Weight Kit
1
*77-6700
75 lb. Wheel Weight
1
92-9670
Bracket Kit
1
24-5790
Rear Weight, 35 lb
1
325-8
Bolt (1/2 x 2 inches)
2
3253-7
Lock washer (1/2 inch)
2
3-8847 Spacer 2
60 inch Side Discharge Deck
with 15 cu. ft. Hopper
0 lb. 110 lb.
3217-9
Nut (1/2 inch)
2
24-5780
Rear Weight Kit
2
108-9682
Rear Weight Kit
1
24-5790
Rear Weight, 35 lb
1
325-8
Bolt (1/2 x 2 inches)
2
3253-7
Lock washer (1/2 inch)
2
3-8847 Spacer 2
72 inch Side Discharge
Deck (Model 30368)
240 lb. 0 lb.
3217-9
Nut (1/2 inch)
2
24-5780
Rear Weight Kit
2
72 inch Rear Discharge
Deck (Model 30369)
or
72 inch Guardian Recycler
Deck (Model 30379)
205 lb. 0 lb.
108-9682
Rear Weight Kit
1
* 75 lb . wheel w eight (included with 15 cu. ft. hopper) required on left wheel
