• Lift ar m pi v ot bushings ( Figure 35 )
Figure 35
• Brak e pi v ot bushings ( Figure 36 )
Figure 36
• Brak e cables (dri v e wheel and brak e pedal
ends) ( Figure 36 )
• PTO tension pi v ot ( Figure 37 )
Figure 37
• R ear PTO bearing ( Figure 37 )
• T ransmission neutral shaft ( Figure 38 )
Note: 2 W heel Dri v e Only
Figure 38
• R ear wheel spindle bushings ( Figure 39 )
