21.Raisetheoorjackuntilthefronttiresareoffofthe
groundhighenoughtoinstallthetrackbeneaththem,
andsupporttheframewithjackstands.
22.Removethefrontandcentertiresfromthewinter
assembly(Figure30).
Figure30
1.Fronttire
23.Carefullyliftthetracksovertherearwheelandfront
hubs.Thedirectionofthetrackrotationisprinted
onthetrack.The‘V’designintherubbertrackmust
pointforward.
CAUTION
Thetrackguideshavemanypinchpoints.
Carefullygrasptherubbertrackontheouter
edgesoutboardofthesteelguideswhen
movingthetrack.
24.Adjusttheoorjacktoasuitableheighttoinstallthe
fronttire.Withanotherperson,liftthefrontofthe
trackenoughtocarefullyinstallthefronttires(Figure
31).
Figure31
25.Adjusttheoorjacktoasuitableheighttoinstallthe
centertire.Liftthecenterofthetrackenoughtoinstall
thecentertire(Figure32).Torquethelugnutsto65to
85ft-lbs(88to115N-m).
Figure32
26.Lowertheoorjackuntilthefrontwheelssupportthe
frame.Installtheatwashers(1/2inch)andlocknuts
onthebogie-pivotstud(Figure29)andtorqueto75
ft-lbs(102N-m).
Note:Youmayneedtomovetheoorjacktotherear
bumpertoraisetherearofthemachinehighenoughto
installtheatwasherandlocknut.
27.Installthesideaccesscoverswiththescrewspreviously
removed(Figure33).
Figure33
1.Accesscovers
28.Installthewinterframeoor-platecovertotheoor
withthescrewspreviouslyremoved(Figure34).
