g009441
Figure64
•Castorforkshaftbushings(2)(Figure65)
•Spindleshaftbearings(3)(locatedunderthe
pulley)(Figure66)
•Idlerarmpivotbushings(2)(Figure66)
g011557
Figure65
g004826
Figure66
CenterLiftAssemblies
•Liftarmcylinderbushings(2each)(Figure67)
•Liftarmballjoints(2)(Figure68)
g020455
Figure67
g011551
Figure68
