SafetyInterlockIndicators
Therearesymbolsonthehourmeterandtheindicatewitha
blacktrianglethattheinterlockcomponentisinthecorrect
position(Figure6).
Fuel-shutoffValve
Closethefuel-shutoffvalve(underthehopper)when
transportingorstoringthemower.
PTOEngagementLever
ThePTOengagementleverisusedtoengagethebladesand
theblower.Pulltheleveruptoengagethebladesandblower.
Todisengagethebladesblower,pushthePTOengagement
leverdown.
BatteryIndicatorLight
WhentheignitionkeyisinitiallyturnedtotheRunposition
forafewseconds,thebatteryvoltagewillbedisplayedinthe
areawherethehoursarenormallydisplayed.
Thebatterylightturnsonwhentheignitionisturnedonand
whenthechargeisbelowthecorrectoperatinglevel(Figure
6).
EngineOilTemperatureLightand
Buzzer
Theengineoiltemperaturelightmonitorsthetemperatureof
theengineoil.Anilluminatedengineoiltemperaturelightand
intermittentbuzzingsoundsignalstheengineisoverheating.
ElectronicControlUnitMalfunction
IndicatorLight
Theelectroniccontrolunit(ECU)continuouslymonitorsthe
operationoftheEFIsystem.
Ifthesystemdetectsaproblemorfault,themalfunction
indicatorlight(MIL)illuminates.
TheMILislocatedintherightconsolepanel.
IftheMILilluminates,performtheinitialtroubleshooting
checks;refertotheMILsectionin(page).
Ifthesechecksdonotcorrecttheproblem,furtherdiagnosis
andservicingbyanAuthorizedServiceDealerisnecessary.
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesis
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww .Toro.comforalistofallapproved
attachmentsandaccessories.
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Width:
42-inchMower
Deck
48-inchMower
Deck
WithoutMower
Deck
108.2cm(42.6
inches)
108.2cm(42.6
inches)
WithMowerDeck
109.7cm(43.2
inches)
125.0cm(49.2
inches)
Length:
42-inchMower
Deck
48-inchMower
Deck
WithoutMower
Deck
170.9cm(67.3
inches)
170.9cm(67.3
inches)
MowerDeck—Up
209.3cm(82.4
inches)
207.6cm(81.8
inches)
Mower
Deck—Down
233.2cm(91.8
inches)
240.0cm(94.5
inches)
Height:
42-inchMowerDeck48-inchMowerDeck
130.0cm(51.2inches)130.0cm(51.2inches)
Weight:
42-inchMowerDeck48-inchMowerDeck
517kg(1140lb)531kg(1170lb)
