6.Removethesafetylteronlyifyouintendtoreplaceit.
Important:Donotattempttocleanthesafety
lter.Ifthesafetylterisdirty,thentheprimary
lterisdamaged.Replacebothlters.
7.Inspecttheprimarylterfordamagebylookinginto
thelterwhileshiningabrightlightontheoutsideof
thelter.Holesinthelterwillappearasbrightspots.
Ifthelterisdamaged,discardit.
ServicingthePrimaryFilter
•Iftheprimarylterisdirty,bent,ordamaged,replaceit.
•Donotcleantheprimarylter.
ServicingtheSafetyFilter
Replacethesafetylter,nevercleanit.
Important:Neverattempttocleanthesafetylter.
Ifthesafetylterisdirty,thentheprimarylteris
damaged.Replacebothlters.
InstallingtheFilters
Important:Topreventenginedamage,alwaysoperate
theenginewithbothairltersandcoverinstalled.
1.Ifinstallingnewlters,checkeachlterforshipping
damage.Donotuseadamagedlter.
2.Iftheinnerlterisbeingreplaced,carefullyslideitinto
thelterbody(Figure31).
3.Carefullyslidetheprimarylterovertheinnerlter
(Figure31).
Note:Ensurethattheprimarylterisfullyseatedby
pushingonitsouterrimwhileinstallingit.
Important:Donotpressonthesoftinsidearea
ofthelter.
4.Installtheaircleanercoverandsecurethelatches
(Figure31).
ServicingtheEngineOil
OilType:Detergentoil(APIserviceclassSJorhigher)
OilCapacity(Non-EFIengines):withalterchange,
1.8L(1.9USqt);withnolterchange,1.6L(1.7USqt)
OilCapacity(EFIengines):withalterchange,1.9L(2.0
USqt);withnolterchange,1.6L(1.7USqt)
Viscosity:Seethetablebelow.
g012991
0
0
50
SAE 30
Figure32
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Note:Checktheoilwhentheengineiscold.
WARNING
Contactwithhotsurfacesmaycausepersonal
injury.
Keephands,feet,face,clothingandotherbody
partsawayfromthemuferandotherhotsurfaces.
Important:Donotoverllthecrankcasewithoil
becausedamagetotheenginemayresult.Donotrun
enginewithoilbelowthelowmarkbecausetheengine
maybedamaged.
1.Movethespeedcontrollevertotheneutralposition
tostopthemachine.
2.DisengagethePTO,engagetheparkingbrake,stopthe
engine,andwaitforallmovingpartstostop.
3.Allowtheenginetocool.
4.Raisethehopper
5.Cleantheareaaroundthedipstick(Figure33).
6.Removethedipstickandwipetheoiloff.
7.Insertthedipstickandpushitallthewaydowninto
thetube.
8.Removethedipstickandreadtheoillevel.
