g000960

Figure48

1.Positive(+)batterypost3.Red(+)chargerlead

2.Negative(–)batterypost4.Black(–)chargerlead

InstallingtheBattery

1.Positionthebatteryinthetraywiththeterminal

postsoppositefromthehydraulictank(Figure

47).

2.Installthepositive(red)batterycabletothe

positive(+)batteryterminal.

3.Installthenegative(black)batterycableand

groundwiretothenegative(-)batteryterminal.

4.Securethecableswith2bolts,2washers,and

2locknuts(Figure47).

5.Slidetheredterminalbootontothepositive

(red)batterypost.

6.Installtheclampandsecureitwiththewingnuts

andJ-hooks(Figure47).

AdjustingtheSafety

Switches

Adjustallsafetyswitchessothattheplungerextends

4.8mmto6.4mm(3/16inchto1/4inch)fromthe

switchbodywhentheplungeriscompressed(Figure

49).

g006849

Figure49

1.4.8to6.4mm(3/16to1/4inch)

ServicingtheFuses

Theelectricalsystemisprotectedbyfuses.Itrequires

nomaintenance;however,ifafuseblowscheckthe

component/circuitforamalfunctionorshort.

1.Thefusesarelocatedonrightsidebehindthe

seat.

2.Toreplacethefuses,pulloutonthefuseto

removeit.

3.Installanewfuse.
