Toro 74310 - The Safety Interlock System; Driving Forward or Backward

7.Closethefuelshut-offvalvewhenthemachinewillnot
beinuseforafewdays,whentransporting,orwhen
theunitisparkedinsideabuilding.
TheSafetyInterlockSystem
CAUTION
Ifsafetyinterlockswitchesaredisconnectedor
damagedthemachinecouldoperateunexpectedly
causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
dailyandreplaceanydamagedswitchesbefore
operatingthemachine.
UnderstandingtheSafetyInterlock
System
Thesafetyinterlocksystemisdesignedtopreventtheengine
fromstartingunless:
•Theparkingbrakeisengaged.
•ThePTOengagementleverisdisengaged.
•Thespeedcontrolleverisintheneutralposition
Thesafetyinterlocksystemisdesignedtostoptheengine
whenyourisefromtheseatwhenthePTOisengaged.
Thehourmeterhassymbolstonotifytheuserwhenthe
interlockcomponentisinthecorrectposition.Whenthe
componentisinthecorrectposition,atrianglewilllightup
inthecorrespondingsquare.
Figure18
1.Triangleslightupwhen
theinterlockcomponents
areinthecorrectposition
3.Hour/Voltagedisplay
2.Hopperup4.Lowvoltageindicatorlight
TestingtheSafetyInterlockSystem
ServiceInterval:Beforeeachuseordaily
Testthesafetyinterlocksystembeforeyouusethemachine
eachtime.Ifthesafetysystemdoesnotoperateasdescribed
below,haveanAuthorizedServiceDealerrepairthesafety
systemimmediately.
1.Sittingontheseat,engagetheparkingbrake,movethe
PTOengagementlevertoon,andmovethespeed
controllevertoneutralposition.Trystartingthe
engine;theengineshouldnotcrank.
2.Sittingontheseat,engagetheparkingbrakeandmove
thePTOengagementlevertooff.Movethespeed
controlleveroutofneutralposition.Trystartingthe
engine;theengineshouldnotcrank.
3.Sittingontheseat,disengagetheparkingbrake,move
thePTOengagementlevertooff,andmovethespeed
controllevertoneutralposition.Trystartingthe
engine;theengineshouldnotcrank.
4.Sittingontheseat,engagetheparkingbrake,move
thePTOengagementlevertooffandmovethespeed
controllevertoneutralposition.Nowstarttheengine.
Whiletheengineisrunning,releasetheparkingbrake,
engagethePTOengagementlever,andriseslightly
fromtheseat;theengineshouldstop.
5.Sittingontheseat,engagetheparkingbrake,move
thePTOengagementlevertooffandmovethespeed
controllevertoneutralposition.Nowstarttheengine.
Movethespeedcontrolleverforward;theengine
shouldstop.
DrivingForwardorBackward
Thethrottlecontrolregulatestheenginespeedasmeasured
inrpm(revolutionsperminute).Placethethrottlecontrolin
thefastpositionforbestperformance.Alwaysoperateinthe
fullthrottlepositionwhenmowing.
CAUTION
Machinecanspinveryrapidly.Operatormaylose
controlofmachineandcausepersonalinjuryor
damagetomachine.
•Usecautionwhenmakingturns.
•Slowthemachinedownbeforemakingsharp
turns.
DrivingForward
Note:Tobeginmovement(forwardorbackward)the
operatormustbeintheseat,thebrakelevermustbe
disengaged(pusheddown)beforethespeedcontrollevercan
bemovedforwardortheenginewillstop.
Tostop,pullthespeedcontrollevertotheneutralposition.
1.Starttheengine.
2.Releasetheparkingbrake;refertoReleasingthe
ParkingBrake(page16).
19
