Toro 74310 - Aligning the Pump Drive Pulley; Adjusting the PTO Brake Spring; Adjusting the Hopper Door

Note:Useastraightedgetoalignallthreesurfaces.
Figure58
1.Alignthethreepumpdrive
pulleysurfacesshownwith
thispatternwithin0.8to
1.6mm(1/32inchto1/16
inch).
2.AlignthethreePTOdrive
pulleysurfacesshownwith
thispatternwithin0.8to
1.6mm(1/32inchto1/16
inch).
9.Tightenthefourenginemountingboltsandfour
jackshaftmountingbolts.Checkthealignmentafter
tightening.
10.Installthepumpbelttensionspring.
11.Swingthefueltankinandinstalltankmountingnuts.
12.Alignthepumpdrivepulley;AligningthePumpDrive
Pulley(page46).
AligningthePumpDrivePulley
Thepumpdrivepulleyalignmentisnecessaryforanyofthe
followingconditions:
•Theenginemountingboltshavebeenloosenedorthe
enginehasbeenmovedorreplaced.
•Thepumppulleyshavebeenloosened,moved,or
replaced.
•ThePTOpulleyalignmenthasbeenperformed;referto
AligningthePTODrivePulley(page45).
1.Stopthemachineandmovethespeed-controlleverto
theneutralposition.
2.DisengagethePTO,engagetheparkingbrake,stopthe
engine,andwaitforallmovingpartstostop.
3.Loosenthesetscrewsonbothpumppulleys.
4.Usingastraightedge,aligneachpumppulleywiththe
enginepulleybyslidingitalongthepumpshaft(Figure
58).
5.Tightenthepulleysetscrewsandcheckthealignment.
AdjustingthePTOBrake
Spring
ThePTObrakespringadjustmentisonlynecessaryifthe
blowerhasbeenremovedorreplacedorifthePTOdrive
idlerarmhasbeendisassembled.
1.Stopthemachineandmovethespeed-controlleverto
theneutralposition.
2.DisengagethePTO,engagetheparkingbrake,stopthe
engine,andwaitforallmovingpartstostop.
3.Locatethebrakespringandthreadthetwojamnuts
outtotheendofthebrakespringrod(Figure59).
4.Tightenthejamnutstogetheratendofthebrake-spring
rod.
Figure59
1.Tightenthejamnutshere
2.PTOBrakespringassembly
AdjustingtheHopperDoor
1.Stopthemachineandmovethespeed-controlleverto
theneutralposition.
2.DisengagethePTO,engagetheparkingbrake,stopthe
engine,andwaitforallmovingpartstostop.
3.Loosenthesixdoorhingenuts(Figure60).
4.Openthedoorandplacea3/8inchrubberstripor
3/8inchdiameterhosebetweenthehopperandthe
hopperdoor(Figure60).
5.Closethedoorandpushittightagainstthehopper.
6.Tightenthehingehardware.Openthehopperdoor
andremovetherubberstrip.
46
