g006788

Figure78

1.Springanchorpinunderconsole

2.Securespringswithawasherandhairpincotter

3.Slidethespringontothespring-anchorpin

5.Removethespringfromthespringanchor.

Repeatforothersideofthemachine.

6.Unlatchthemowerdeckfromtheraisedposition

andslowlylowerthemowerdecktoground;

refertoLoweringtheMowerDecktothe

OperatingPosition(page16).

Note:Themowerdeckbecomesheavierwhen

youremovethespringsfromtheanchors.Lower

themowerdeckcarefully.

7.Removethelynchpinsatthefrontofthepush

armsonbothsidesofthemachine(Figure79).

g233982

Figure79

1.Pusharm

2.Lynchpin

3.Push-armtube

8.Loosentheboltsattachedtotherubberguard

(Figure80).

g036545

Figure80

1.Bolts

2.Rubberguard

9.Unlatchtheseatanddisconnectthedriveshaft

usingthequickcoupleratthejackshaft(Figure

81).RefertoUnlatchingtheSeat(page19)
