Safety-InterlockIndicators
Symbolsonthehourmeterindicatewithablacktrianglethat
theinterlockcomponentisinthecorrectposition(Figure5).
Battery-IndicatorLight
IftheignitionkeyisturnedtotheONpositionforafew
seconds,thebatteryvoltagedisplaysintheareawherethe
hoursarenormallydisplayed.
Thebatterylightturnsonwhentheignitionisturnedonand
whenthechargeisbelowthecorrectoperatinglevel(Figure
5).
ThrottleControl
ThethrottlecontrolisvariablebetweenFastandSlow
(Figure5).
Blade-ControlSwitch(PTO)
Usetheblade-controlswitch(PTO)toengageanddisengage
themowerblades(Figure5).
IgnitionSwitch
Usetheignitionswitchtostartthemowerengine(Figure5).
Theswitchhas3positions:OFF,RUN,andSTART.
Motion-ControlLevers
Themotion-controlleversareusedtodrivethemachine
forwardandreverseandtoturneitherdirection(Figure5).
Fuel-ShutoffValve
Closethefuel-shutoffvalve(locatedontheleftsideofthe
fueltank)whentransportingorstoringthemower(Figure4).
AccessoryFrame
UsetheaccessoryframetoattachonlyToro-approved
accessoriestothemachine(Figure4).RefertotheOperator’s
Manualfortheaccessoryforinstallationinstructions.
Accessory-FrameLock
Theaccessory-framelockholdstheframeinplaceonthe
machineusingthelockpin.Alwayslocktheframeunlessa
hydraulickitisinstalledwithanaccessoryonthemachine
(Figure4).
AdjustableCasters
Whenusingthemachinewithoutanaccessory,placethe
adjustablecastersinthemowingposition(fronthole)as
showninFigure6.Whenusingthemachinewithan
accessory,refertotheOperator’sManualforthataccessory
forthecorrectcasterposition.
Figure6
RightCasterShown
1.Mowingposition2.Accessorypositions
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
52-inchMowers
Widthwithdeectordown173cm(68inches)
Widthwithdeectorraised137cm(54inches)
Lengthwithplatformdown191cm(75inches)
Lengthwithplatformup155cm(61inches)
Height
122cm(48inches)
Weight
412kg(908lb)
60-inchMowers
Widthwithdeectordown193cm(76inches)
Widthwithdeectorraised157cm(62inches)
Lengthwithplatformdown201cm(79inches)
Lengthwithplatformup165cm(65inches)
Height
122cm(48inches)
Weight
427kg(941lb)
