ServicingtheFuses
Theelectricalsystemisprotectedbyfusesandrequiresno
maintenance.Ifafuseblows,checkthecomponentorcircuit
foramalfunctionorshort.
1.Releasethecushionfromtherearofthemachine.
2.Pulloutthefusetoremoveorreplaceit(Figure53).
3.Installthecushiontotherearofthemachine.
Note:Ensurethatthecorrect-sizefuseisinstalled
Figure53.
Figure53
1.Ignitionfuse—15A3.Powertakeoff(PTO)
fuse—10A
2.Accessory-portfuse—15
A
4.Infocenterfuse—7.5A
DriveSystem
Maintenance
AdjustingtheTracking
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
1.Pushbothcontrolleversforwardthesamedistance.
2.Checkifthemachinepullsto1side.
Note:Ifitdoes,stopthemachineandsettheparking
brake.
3.Releasethecushionfromtherearofthemachine;refer
to(page).
Note:Foreasieraccess,youcanalsoremovethefuel
tank;refertoRemovingtheFuelTank(page36).
4.Rotatetheleftcontrolrodinquarter-turnincrements
untilthemachinetracksstraight(Figure54).
Note:Ifthemachinepullstotheright,shortenthe
controlrodbyrotatingittotheright.Ifthemachine
pullstotheleft,lengthentherodbyrotatingittothe
left.
Note:Onlyadjusttheleftcontrolrodtomatchthe
leftwheelspeedtotherightwheelspeed.Donot
adjusttherightwheelspeed,asthispositionstheright
motion-controlleveroutofthecenterforthecontrol
panelneutral-lockslot.
Important:Donotrotatethecontrolrodtoofar,
asthismaycausethemachinetocreepinneutral.
Figure54
1.Rotatelefttolengthenthe
rod.
3.Rotaterighttoshortenthe
rod.
2.Leftcontrolrod
5.Checkforpropertracking,andadjusttherodas
necessary.
Note:Ifyouareunabletoachievepropertrackingby
adjustingtheleftcontrolrod,contactyourAuthorized
ServiceDealer.
