Toro 74523 - Removing the Fuel Tank; Servicing the Fuel Filter

RemovingtheFuelTank
1.Lowertheplatform.
2.Releasethecushion;referto(page).
3.Removethecrossbracket.
Figure48
4.Removethefueltankandsetitontheoperator
platform.
Note:Ifyouwanttomovethefueltankfurtherfrom
themachine,removethefuelandventlinesfromthe
topofthetank.
ServicingtheFuelFilter
ReplacingtheFuelFilter
ServiceInterval:Every800hours/Yearly(whichevercomes
rst)
Donotinstalladirtylterifitisremovedfromthefuelline.
Note:Wipeupanyspilledfuel.
1.DisengagethePTOandsettheparkingbrake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Closethefuel-shutoffvalve;refertoUsingthe
Fuel-ShutoffValve(page17).
4.ReplacethefuellterasshowninFigure49.
B
A
C
D
g027518
Figure49
36
