ControlsSystem
Maintenance
AdjustingtheMotion-Control
Levers
Ifthemotion-controlleversdonotalignhorizontally,adjust
therightsidemotion-controllever.
1.DisengagethePTO,movethemotion-controlleversto
theneutralposition,andsettheparkingbrake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Pushthemotion-controlleversdownoutofthe
NEUTRAL-LOCKposition(Figure69).
4.Checkiftherightmotion-controlleveraligns
horizontallywiththeleftmotion-controllever(Figure
69).
Figure69
1.Leftmotion-controllever3.Checkthehorizontal
alignmenthere
2.Rightmotion-controllever
intheNeutral-lockposition
4.Rightmotion-controllever
5.Toadjustthemotion-controllevershorizontally,you
mustadjustthecam.
6.Releasethecushionfromtherearofthemachine.
7.Loosenthenutholdingthecam(Figure70).
Figure70
1.Cam
2.Nut
8.Adjustthecamuntilitalignswiththeleft
motion-controlleverandtightenthenutforthecam.
Note:Movingthecamclockwise(inthevertical
position)lowersthehandle;movingthecam
counterclockwise(intheverticalposition)raisesthe
handle.
Important:Ensurethattheatportionofthe
camdoesnotgoaboveaverticalposition(rightor
left);otherwiseyoumaydamagetheswitch.
9.Repeatsteps3through8fortheleftmotion-control
lever.
