Toro 74523 - Positioning the Flow Baffle; Using the MID-Size Weight

PositioningtheFlowBafe
Thefollowingguresareonlyforrecommendeduse.
Adjustmentsvarybygrasstype,moisturecontent,andthe
heightofthegrass.
Note:Iftheenginepowerdrawsdown,andthemower
groundspeedisthesame,openupthebafe.
PositionA
Thisisthefull,rearposition(seeFigure30).Usethisposition
forthefollowing:
•Inshort,lightgrassmowingconditions
•Indryconditions
•Smallergrassclippings
•Propelsgrassclippingsfartherawayfromthemower
G012677
Figure30
PositionB
Usethispositionwhenbagging(Figure31).
G012678
Figure31
PositionC
Thisisthefull,openposition(Figure32).Useforthis
positionforthefollowing:
•Intall,densegrassmowingconditions
•Inwetconditions
•Lowerstheengine-powerconsumption
•Allowsincreasedgroundspeedinheavyconditions
G012679
Figure32
UsingtheMid-SizeWeight
•Installweightstoimprovebalance.Youcanaddor
removeweightstocreateoptimizedperformanceunder
differentmowingconditionsandforyourpreference.
•Addorremoveweights1atatimeuntilyouachievethe
desiredhandlingandbalance.
Note:ContactanAuthorizedServiceDealertoordera
WeightKit.
WARNING
Excessiveweightchangescanaffectthehandling
andoperationofthemachine.Thiscouldcause
seriousinjurytoyouorbystanders.
•Makeweightchangesinsmallincrementsonly.
•Evaluatethemoweraftereachweightchangeto
ensurethatyoucanoperatethemachinesafely.
26
