g008955
Figure26
TransportLockPositions
1.Transportlock3.Unlockposition—doesnot
lockthemowerdeckinto
transportposition
2.Lockposition—mower
deckwilllockintotransport
position
AdjustingtheHeight-of-CutPin
Theheightofcutisadjustedfrom25to140mm(1to
5-1/2inches)in6mm(1/4inch)incrementsbymoving
theclevispinintodifferentholelocations.
1.Movethetransportlocktothelockposition.
2.Pushonthedeck-liftpedalwithyourfootand
raisethemowerdecktothetransportposition
(alsothe140mm(5-1/2inch)cutting-height
position);refertoFigure27.
3.Toadjust,rotatethepin90degreesandremove
thepinfromtheheight-of-cutbracket(Figure
27).
4.Selectaholeintheheight-of-cutbracket
correspondingtotheheightofcutdesired,and
insertthepin(Figure27).
5.Pushonthedecklift,pullbackonthetransport
lock,andslowlylowerthemowerdeck.
27
