Toro 74990 - Adjusting the Anti-Scalp Rollers; Adjusting the Flow Baffle Cam Locks

g029840
Figure27
1.Deck-liftpedal
3.Transportlock
2.Height-of-cutpin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,itis
recommendedtoadjusttheheightoftheanti-scalp
rollers.
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheneutral-locked
position,andsettheparkingbrake.
2.Stoptheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Adjusttheanti-scalprollersasshowninFigure
28,Figure29,andFigure30.
g029955
Figure28
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
g029956
Figure29
1.Anti-scalproller3.Flangenut
2.Bushing4.Bolt
g029957
Figure30
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
AdjustingtheFlowBafe
CamLocks
Thisprocedureisapplicableonlytomachineswith
theowbafelocks.Certainmodelswillhavenuts
andboltsin-placeoftheowbafelocksandcanbe
adjustedthesame.
Themowerdischargeowcanbeadjustedfor
differenttypesofmowingconditions.Positionthecam
locksandbafetogivethebestqualityofcut.
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheneutral-locked
positionandsettheparkingbrake.
2.Stoptheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Toadjustthecamlocks,swingtheleverupto
loosenthecamlock(Figure31).
28
