Toro 74990 - Positioning the Flow Baffle

4.Adjustthebafeandcamlocksintheslotsto
thedesireddischargeow.
5.Swingtheleverbackovertotightenthebafe
andcamlocks(Figure31).
6.Ifthecamlocksdonotlockthebafeintoplace
oritistootight,loosentheleverandthenrotate
thecamlock.Adjustthecamlockuntilthe
desiredlockingpressureisachieved.
g027727
Figure31
PositioningtheFlowBafe
Thefollowingguresareonlyrecommendationsfor
use.Adjustmentswillvarybygrasstype,moisture
content,andheightofgrass.
Note:Iftheenginepowerdrawsdownandthe
mowergroundspeedisthesame,openupthebafe.
PositionA
Thisisthefullrearposition.Thesuggestedusefor
thispositionisasfollows:
•Useforshort,lightgrassmowingconditions.
•Useindryconditions.
•Useforsmallergrassclippings.
•Usetopropelgrassclippingsfartherawayfrom
themower.
g005832
Figure32
PositionB
Usethispositionwhenbagging.Alwaysalignitwith
thebloweropening.
29
