Adjusttherear,shockassemblies(Figure38).
g030024
g030019
Figure38
AdjustingtheFront,Shock
Assembly
Thefront,shockassemblyissetatthemiddleposition
andisnormallynotadjusted.
Toadjustthefront,shockassembly,opentheoor
panandadjustitbyusingaspannerwrench(T oro
partno.132–5069)oraslip-jointpliers(Figure39).
g030569
Figure39
1.Middleposition
3.Softride
2.Firmride
UsingtheDriveWheel
ReleaseValves
WARNING
Handsmaybecomeentangledintherotating
drivecomponentsbelowtheenginedeck,
whichcouldresultinseriousinjury.
Stoptheengine,removethekey,andallow
allmovingpartstostopbeforeaccessingthe
drivewheelreleasevalves.
WARNING
Theengineandhydraulicdriveunitscan
becomeveryhot.Touchingahotengineor
hydraulicdriveunitscancausesevereburns.
Allowtheengineandhydraulicdriveunitsto
coolcompletelybeforeaccessingthedrive
wheelreleasevalves.
Thedrivewheelreleasevalvesarelocatedintheback
ofeachhydraulicdriveunit,undertheseat.
Note:Makesurethereleasevalvesareinthefully
horizontalpositionwhenoperatingthemachineor
severedamagetothehydraulicsystemcanoccur.
1.DisengagethePTO(blade-controlswitch)and
turntheignitionkeytooff.Movetheleversto
