Toro 74990 - Adjusting the Motion-Control Damper; Adjusting the Motion-Control Neutral-Lock Pivot

Adjustingthe
Motion-ControlDamper
Thetopdampermountingboltcanbeadjustedto
obtainamoredesiredmotion-controlleverresistance.
SeeFigure85formountingoptions.
g008620
Figure85
Right-handmotioncontrolshown
1.Torquethelocknutto23N-m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
Adjustingthe
Motion-Control
Neutral-LockPivot
Theangednutcanbeadjustedtoobtainamore
desiredmotion-controlleverresistancewhenmoving
ittotheneutral-lockposition.SeeFigure86for
adjustmentoptions.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesired
feel.
Formoreresistance,tightentheangednut.
Forlessresistance,loosentheangednut
3.Tightenthejamnut.
g008621
Figure86
1.Flangednut2.Jamnut
60
