Toro 74990 - Checking and Cleaning the Hydraulic Units

g004218
Figure75
1.Engineguard4.Fanhousing
2.Engineairintakescreen
5.Screw
3.Bolt
CheckingandCleaningthe
HydraulicUnits
ServiceInterval:Beforeeachuseordaily
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Movetheseatforward.
4.Cleanthedebrisandgrassfromthehydraulic
units(Figure76).
5.Positiontheseat.
g029645
g015117
Figure76
1.Hydraulicunits
54
