Toro 74990 - Servicing the Engine Oil

g009031
Figure49
1.Air-cleanerclamps
3.Primaryairlter
2.Air-cleanercover
4.Secondaryairlter
ServicingthePrimaryFilter
1.Donotcleanthepaperlter,replaceit(Figure
49).
2.Inspecttheelementfortears,anoilylm,or
damagetotherubberseal.
3.Replacethepaperelementifitisdamaged.
ServicingtheSecondaryFilter
Donotcleanthesecondarylter,replaceit.
Important:Neverattempttocleanthesecondary
lter.Ifthesecondarylterisdirty,thenthe
primarylterisdamagedandyoushouldreplace
bothlters.
InstallingtheFilters
Important:Topreventenginedamage,always
operatetheenginewithbothairltersandcover
installed.
1.Ifinstallingnewlters,checkeachlterfor
shippingdamage.Donotuseadamagedlter.
2.Ifthesecondarylterisbeingreplaced,carefully
slideitintothelterbody(Figure49).
3.Carefullyslidetheprimarylteroverthe
secondarylter(Figure49).Ensurethatitis
fullyseatedbypushingontheouterrimofthe
lterwhileinstallingit.
Important:Donotpressonthesoftinside
areaofthelter.
4.Installtheaircleanercoverwiththebreathercap
downandrotatesotheretainingclampslockthe
coverinplace(Figure49).
ServicingtheEngineOil
OilType:Detergentoil(APIserviceSG,SH,SJ,or
SL)
CrankcaseCapacity:withalterchange,2.1L(2.2
USqt);withoutalterchange,1.8L(1.9USqt)
Viscosity:Seethetablebelow.
g004216
Figure50
Note:Useofmulti-gradeoils(5W-20,10W-30,or
10W-40)willincreaseoilconsumption.Checktheoil
levelmorefrequentlywhenusingthem.
CheckingtheEngine-OilLevel
ServiceInterval:Beforeeachuseordaily
Note:Checktheoilwhentheengineiscold.
WARNING
Contactwithhotsurfacesmaycausepersonal
injury.
Keephands,feet,face,clothingandother
bodypartsawayfromthemuferandother
hotsurfaces.
Important:Donotoverllthecrankcasewithoil
becausedamagetotheenginemayresult.Donot
runenginewithoilbelowthelowmarkbecause
theenginemaybedamaged.
1.DisengagethePTO,movethemotion-control
leverstotheneutral-lockedpositionandsetthe
parkingbrake.
2.Stoptheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition(Figure51).
