Toro Groundsmaster 3310 Series User Manual

g258473
Figure30
1.TRANSPORTposition
2.SERVICEposition
RotatingtheCuttingUnittothe
SERVICEPosition
Performthisproceduretorotatethecuttingunitfrom
theTRANSPORTpositiontotheSERVICEposition.
WARNING
Ifyouleavethekeyintheswitch,someone
couldaccidentlystarttheengineand
seriouslyinjureyouorotherbystanders.
Removethekeyfromtheswitchanddonot
starttheenginewiththecuttingunitinthe
SERVICEposition.
1.Parkthemachinealevelsurface.
2.Presstheliftswitchtoraisethecuttingunitto
theTRANSPORTposition.
3.Engagetheparkingbrake,shutofftheengine,
andremovethekey.
4.Removethepinsfromtheheight-of-cutplates
(Figure31).
g258474
Figure31
1.Height-of-cutpins2.Height-of-cutplates
5.Rotatethecuttingunit(Figure32)sothatthe
latchengageswiththetie-downbracket(Figure
33).
WARNING
Thecuttingunitisheavy.
Useassistancewhenyouliftthecutting
unit.
g298275
Figure32
35
