Toro Groundsmaster 3310 Series User Manual

g298276
Figure33
RotatingtheCuttingUnittothe
TRANSPORTPosition
Performthisproceduretorotatethecuttingunitfrom
theSERVICEpositiontotheTRANSPORTposition.
1.Releasethecutting-unitlatchfromthetie-down
bracket(Figure34)byslightlyrotatingthecutting
unitslightlyforward(refertoFigure32)and
pullingthelatchhandleforward.
g298277
Figure34
2.Slowlyrotatethecuttingunitdownuntilthepin
contactsthelift-armplate(AinFigure35).
g298288
Figure35
1.Lift-armplate
2.Pin
3.Useyourfoottopressdownonthecuttingunit,
thenpulloutonthepin(BinFigure35)toletthe
cuttingunitsettleintotheTRANSPORTposition.
4.Inserttheheight-of-cutpinsthroughthe
height-of-cutplatesandchains.
